TCL Air Conditioner Service Manual
40
Outdoor Unit- TAC-18CS/K
No. Part No. Part Name Q’ty Remark
1 1080050026 Grille 1
Optional
2 1080050011 Top Cover 1
3 1210500109 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040059 Outdoor Motor 1
6 1070030012 Propeller Fan 1
7 1080050001 Left Grille Supporter 1
8 1080050007 Left Grille 1
9 1080050009 Front Plate 1
10 1080320112 Fan Guard 1
11 1213590202 Capillary Assembly 1
12 1100010011 Compressor and its Accessories 1
13 1120500211 Discharge Pipe 1
14 1120500210 Suction Pipe 1
15 1210500106 Base 1
16 1120120016 Two-way Valve 1
17 1080050003 Valve Supporter 1
18 1120130021 Three-way Valve 1
19 1080050002 Right Plate 1
20 1073551103 Electrical Box Cover 1
21 1080010006 Capacitor Strip 1
22 1070040003 Cable Clamp(φ8) 1
23 1170200019 Terminal 1
24 1170100007 Compressor Capacitor 1
25 1170100027 Fan Motor Capacitor 1
26 1080020001 Electrical Parts Box 1
27 1190070020 Base Carton 1
28 1190070002 Cabinet Carton 1
29 1190070022 Base Foaming 1
30 1190070021 Cover Forming 1
Not shown in the Explosion
view.
To Next Page
