TCL Air Conditioner Service Manual
41
Part List
Outdoor Unit- TAC-18CHS/K
No. Part No. Part Name Q’ty Remark
1 1084530501 Grille 1
Optional
2 1080050011 Top Cover 1
3 1210500351 Condenser 1
4 1080050004 Outdoor Motor Supporter 1
5 1170040059 Outdoor Motor 1
6 1070030012 Propeller Fan 1
7 1080050001 Left Grille Supporter 1
8 1080050007 Left Grille 1
9 1080050009 Front Plate 1
10 1080320112 Fan Guard 1
11 1100010011 Compressor And It Accessories 1
12 1120500107 Suction Pipe 1
13 1120500109 Three-way Valve connecting Pipe 1
14 1120500108 Discharge Pipe 1
15 1120110003 4-way Vane Assembly 1
16 1120500110 Condenser connecting Pipe 1
17 1210500106 Base 1
18 1080050002 Right Plate 1
19 1120120016 Two-way Valve 1
20 1080050003 Valve Supporter 1
21 1120130021 Three-way Valve 1
22 1073551103 Electrical Box Cover 1
23 1070040001 Cable Clamp(φ6) 1
24 1170040003 Cable Clamp(φ8) 1
25 1170200020 Terminal 1
26 1170100027 Fan Motor Capacitor 1
27 1170100007 Compressor Capacitor 1
28 1080010006 Capacitor Strip 1
29 1080020001 Electrical Parts Box 1
30 1210700203 Capillary Assembly 1
31 1174561802 Outdoor Sensor 1
31 1190070020 Base Carton 1
32 1190070002 Cabinet Carton 1
33 1190070004 Upper Forming 1
34 1190070021 Base Forming 1
Not show in the explosion
To Next Page
