TCL Air Conditioner Service Manual
43
Part List
Outdoor Unit- TAC-24CHS/K
No. Part No. Part Name Q’ty Remark
1 1084530501 Grille 1
Optional
2 1084530504 Top Cover 1
3 1210700211 Condenser 1
4 1084530510 Outdoor Motor Supporter 1
5 1170040063 Outdoor Motor 1
6 1070030017 Propeller Fan 1
7 1084530516 Left Plate 1
8 1084530514 Front Plate 1
9 1084530515 Fan Guard 1
10 1100060013 Compressor And It Accessories 1
11 1210700203 Capillary Assembly 1
12 1120700215 Suction Pipe 1
13 1120700205 Three-way Valve connecting Pipe 1
14 1120700203 Discharge Pipe 1
15 1120110001 4-way Vane Assembly 1
16 1120700206 Condenser connecting Pipe 1
17 1214561809 Base 1
18 1120120011 Two-way Valve 1
19 1084530502 Valve Supporter 1
20 1120130013 Three-way Valve 1
21 1084530503 Right Plate 1
22 1074530503 Electrical Box Cover 1
23 1074060118 Cable Clamp 1
24 1170200036 Terminal 1
25 1080010006 Capacitor Strip 1
26 1170100007 Compressor Capacitor
27 1170100030 Fan Motor Capacitor 1
28 1080010004 Electrical Parts Box
29 1174561801 AC Contactor
30 1174561802 Outdoor Sensor
31 1190070003 Base Carton
32 1190070013 Cabinet Carton 1
33 1190070004 Upper Carton 1
Not show in the explosion
1
1
1
1
1
