Part List
Outdoor Unit- TAC-18CHSA/M
No. Part No. Part Name Q’ty Remark
1 Grille 1
Optional
2 Top Cover 1
3 Condenser 1
4 Outdoor Motor Supporter 1
5 Outdoor Motor 1
6 Propeller Fan 1
7 Left Plate 1
8 Front Plate 1
9 Fan Guard 1
10 Compressor And It Accessories 1
11 Capillary Assembly 1
12 Suction Pipe 1
13 Three-way Valve connecting Pipe 1
14 Discharge Pipe 1
15 4-way Vane Assembly 1
16 Condenser connecting Pipe 1
17 Base 1
18 Two-way Valve 1
19 Valve Supporter 1
20 Three-way Valve 1
21 Right Plate 1
22 Electrical Box Cover 1
23 Cable Clamp 1
24 Terminal 1
25 Capacitor Strip 1
26 Compressor Capacitor 1
27 Fan Motor Capacitor 1
28 Electrical Parts Box 1
29 Outdoor Sensor 1
30 Base Carton 1
31 Cabinet Carton 1
31 Upper Carton 1
32
33
Not show in the explosion
