TCL Air Conditioner Service Manual
30
Indoor Unit- TAC-18CSA/M,TAC-18CHSA/M,TAC24CSA/M,TAC-24CHSA/M
No. Part No. Part Name Q’ty Remark
1 Installation Plate 1
2 Base 1
3 Cross Fan 1
4 Bearing Mount 1
5 Evaporator 1
6 Water Drainage Assembly 1
7 Vertical Vane Assembly 2
8 Face Frame 1
9 Screw Cover 3
10 Display PCB 1
11 Display PCB Box 1
12 Air Filter 2
13 Front Panel 1
14 Electrical Box Cover 1
15 Power Supply Cord 1
16 Vane A 1
17 Vane B 1
18 Drainage Hose 1
19 Cable Clamp 1
20 Vane Motor 2
21 Terminal1
Terminal2
1
1
22 Terminal Fixing Board 1
23 Sensor Holder 1
24 Main PCB 1
25 Indoor Motor Cover 1
26 Indoor Motor 1
27 Electrical Box 1
28 Transformer 1
29 Pipe Temp. Sensor & Room
Temp. Sensor Assembly
1
30 Remote Controller 1
31 Remote Controller Supporter 1
32 Indoor Carton 1
33 Left Foaming 1
34 Right Foaming 1
35 Middle Pasteboard Supporter 1
36 Middle Foaming Supporter 1
Not shown in Explosion
view
To Next Page
