TCL Air Conditioner Service Manual
32
Outdoor Unit- TAC-18CSA/M
No. Part No. Part Name Q’ty Remark
1 Grille 1
Optional
2 Top Cover 1
3 Condenser 1
4 Outdoor Motor Supporter 1
5 Outdoor Motor 1
6 Propeller Fan 1
7 Left Plate 1
8 Front Plate 1
9 Fan Guard 1
10 Suction Pipe 1
11 Base 1
12 Compressor and its Accessories 1
13 Right Plate 1
14 Valve Supporter 1
15 Two-way Valve 1
16 Three-way Valve 1
17 Electrical Box Cover 1
18 Capacitor Strip 1
19 Cable Clamp 1
20 Terminal 1
21 Compressor Capacitor 1
22 Fan Motor Capacitor 1
23 Electrical Parts Box 1
24 Discharge Pipe 1
25 Capillary Assembly 1
26 Base Carton 1
27 Cabinet Carton 1
28 Cover Carton 1
Not shown in the Explosion
view.
To Next Page
