Outdoor Unit- TAC-07
CHSA/M,TAC-09CHSA/M , TAC-12CHSA/M
No. Part No. Part Name Q’ty Remark
1 Grille 1
Optional
2 Top Cover 1
3 Condenser 1
4 Outdoor Motor Supporter 1
5 Outdoor Motor 1
6 Propeller Fan 1
7 Left Grille Supporter 1
8 Left Grille 1
9 Front Plate 1
10 Fan Guard 1
11 Compressor And It Accessories 1
12 Suction Pipe 1
13 Three-way Valve connecting Pipe 1
14 Discharge Pipe 1
15 4-way Vane Assembly 1
16 Condenser connecting Pipe 1
17 Base 1
18 Right Plate 1
19 Two-way Valve 1
20 Valve Supporter 1
21 Three-way Valve 1
22 Electrical Box Cover 1
23 Cable Clamp(φ6) 1
24 Cable Clamp(φ7) 1
25 Terminal 1
26 Fan Motor Capacitor
27 Compressor Capacitor 1
28 Capacitor Strip 1
29 Electrical Parts Box 1
30 Capillary Assembly 1
31 Base Carton 1
32 Cabinet Carton 1
33 Base Foaming 1
34 Cover Forming 1
Not shown in the Explosion
view.
