TCL Air Conditioner Service Manual
5
Technical Specifications
Model No. TAC-24CSA/M TAC-24CHSA/M
Type Cooling Only Heating Pump
Control type Remote Remote
Rated cooling capacity Btu/h 24,000 24,000
Rated heating capacity Btu/h N/A 26,000
EER for cooling Btu/h.w 9.8 9.8
COP for heating W/W N/A 3.2
Moisture removal Liters/h 2.63 2.63
High dB(A) 49 49
Med. dB(A) 46 46
Indoor noise level at
cooling
Low dB(A) 42 42
Outdoor noise level dB(A) 58 58
Electrical Data
Power supply 220V~/50Hz
Voltage Range V
Cooling A 11.5 11.5
Rated current
Heating A N/A
11.2
Cooling W 2430 1130
Rated input
Heating W N/A
1120
Refrigerating System
Refrigerant/Charge Gram R410A/1900g R410A/1900g
Type Rotary Rotary
Model ------------------ -----------------
LRA A ------ -------
Compressor
MFG ----------------- -----------------
Evaporator Louver fin and Grooved tube type (φ7)
Condenser Corrugated fin and Grooved tube type (φ9.53)
Expansion device Capillary tube
Defrosting system Microcomputer controlled reverse system
Fan System
Indoor air circulation m
3
/h 1100 1100
Indoor fan type Cross flow Cross flow
Cooling rpm 1300/1200/1100 1300/1200/1100
Heating rpm N/A 1300/1200/1100
Dry rpm 1100 1100
Indoor fan speed
H/M/L
Sleep rpm 1100 1100
Indoor fan motor output W 12 12
Outdoor air circulation m
3
/h --- ---
Outdoor fan type Propeller fan Propeller fan
Outdoor fan speed rpm 850 850
Outdoor fan motor output W 76 76
Connections
Refrigerant coupling Flare type
Gas Inches 5/8 5/8
Connecting Pipe
Liquid Inches 3/8 3/8
Connecting Wiring
Size × Core
number
Drainage Pipe O.D 16mm
Others
Suitable area m
2
35~48 35~48
Indoor mm 1036×313×204 1036×313×204 Net dimensions
(W x H x D)
Outdoor mm
890×307×660 890×307×660
Indoor kg 14 18
Net weight
Outdoor kg
56 57
Indoor mm 1103×395×280 1103×395×280 Packing dimensions
(W x H x D)
Outdoor mm
975×400×700 975×400×700
Indoor kg 18 18
Gross weight
Outdoor kg 62 63
Loading Capacity 40’/40’HC 64/142/162 64/142/162
