TCL TS7000 User Manual

28
Tip
• IfyoucannotndthemodelnameTCL TS7000 on
your Bluetooth device, press and hold
on the remote
control.YouwillseetheblueLEDashesrapidly.Now
the Sound Bar main unit is entering the pairing mode.
3
4
TCL TS7000
2
1
YourSoundBarsystemisnowsetupandreadytouse.
5
To disconnect the Bluetooth function, you can:
• press
on the Sound Bar main unit or remote
control to switch to another source; or
• disable the Bluetooth function on your device; or
• press and hold
on the remote control for 3
seconds.

TCL TS7000 Specifications

General

Audio decoders	Dolby Digital
RMS rated power	160 W
Audio output channels	2.0 channels
Audio Return Channel (ARC)	Yes
Tweeter diameter	38 mm
Soundbar speaker RMS power	80 W
Signal-to-Noise Ratio (SNR)	97 dB
Subwoofer included	No
Display type	LED
Certification	CE
Product color	Black
TV stand usage	-
Audio formats supported	MP3, WAV
Consumer Electronics Control (CEC)	T-link
HDMI version	1.4
Bluetooth version	4.2
USB 2.0 ports quantity	1
Connectivity technology	Wired
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Soundbar power consumption	40 W
Power consumption (standby)	0.5 W
Cables included	AC, IR
Remote control battery type	AAA
Number of remote control batteries	2
Package depth	134 mm
Package width	992 mm
Package height	152 mm
Package weight	3400 g

Weight and Dimensions

Depth	64 mm
Width	920 mm
Height	98 mm
Soundbar weight	2600 g
