TCL TS8132 User Manual

9
Set up your Sound Bar system
5V[LZ
Make sure you read all the safety information before
you mount the Sound Bar main unit on the wall.
TCL Overseas Marketing Limited bears no
responsibility for accidents or damage caused by
improper wall mounting and screws installation or
Additional tools (not supplied) are required for
installation.
The ideal place to position the Sound Bar main unit is centered
underneath your TV.
You are recommended to place the Sound Bar main unit on
the top of the cabinet and right below the center of your TV.
The distance between the subwoofer and the Sound Bar main
unit should be less than 9.8'.
Make sure you use screws provided or specified by the
authorized manufacturer.
insufficient wall strength, etc.
You can choose to place your Sound Bar below the center
of your TV or mount it on the wall.
Position Your Sound Bar and Subwoofer

TCL TS8132 Specifications

General

Truck type	87 cbm
Pallet width	1000 mm
Pallet height	2000 mm
Pallet length	1200 mm
Pallet net weight	252000 g
Quantity per truck	728 pc(s)
Quantity per pallet	28 pc(s)
Master (outer) case width	1090 mm
Master (outer) case height	355 mm
Number of pallets per truck	26 pc(s)
Master (outer) case net weight	9000 g
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	8720568100012
Package depth	275 mm
Package weight	Weight of the packaged product in gram.
Battery weight	15 g
Remote control battery type	AAA
Number of remote control batteries	2
Audio decoders	Dolby Atmos, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Movie, Music, TV
RMS rated power	350 W
Audio output channels	3.1.2 channels
Enhanced Audio Return Channel (eARC)	Yes
Bluetooth codec	A2DP, AVRCP
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	5.25 \
Display type	LED
Product color	Black
Country of origin	China
Virtual assistant	Amazon Alexa & Google Assistant
Audio formats supported	AAC, ALAC, FLAC, MP3, WAV
Operating temperature (T-T)	0 - 45 °C
Consumer Electronics Control (CEC)	T-link
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Cables included	AC, HDMI
Number of products included	2 pc(s)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Analog audio input	3.5
Sustainability certificates	CE

Weight and Dimensions

Depth	122 mm
Height	65 mm
Weight	6800 g
Soundbar weight	3300 g
Subwoofer width	200 mm
Subwoofer height	325 mm
Subwoofer weight	3500 g
