TCS 682-15 - Page 19

AIR ELIMINATOR ASSEMBLY
640-15
ITEM# DESCRIPTION QTY AF SS
1 Cover 1 64002-2 64002-3
2 Bracket Assembly 1 64019 64019
3 Lock Washer 3 1-126316 1-126316
4 Screw 3 64010 64010
5 Short Link Pin 2 64023 64023
6 Connecting Arm 2 64007 64007
7 Lever Arm 1 64006 64006
8 Cotter Pin 6 1-126318 1-126318
9 Float Assembly 1 64005 64005
10 Pipe Plug 1 2-051913 2-126146
11 Base 1 64003-2 64003-3
12 Gasket 1 64004 64004
13 Shut Off Arm 1 64015 64015
14 Long Link Pin 2 64012 64012
15 Shut Off Valve 1 64016 64016
16 Valve Seat 1 64001 64001
17 External Valve O-Ring 1 64013 64013
18 Internal Valve O-Ring 1 64014 64014
19 Screw 10 64021 64021
640 AIR ELIMINATOR REPAIR INSTRUCTIONS
1) Remove the screws (#19) that bolt the air eliminator base (#11) to the cover assembly (#1).
2) Remove the screws (#4) and washers (#3) that mount the float and bracket assembly (#2) to
the cover assembly (#1). Inspect for damage to float and bracket assembly, making sure no
liquid is inside the float (#9) and o-rings (#17 & 18) are not torn or cut. All foreign particles
must be removed (i.e. dirt, metal shavings, …)
3) Replace all damaged air eliminator parts.
4) Reassemble the float and bracket assembly to the cover assembly with screws (#4). Do not
tighten screws until the bracket assembly (#2) is properly adjusted between the shut-off valve
(#15) and seal (#18).
5) Once float and bracket assembly are tightened, reassemble air eliminator.
