HE220A AND HE260A BYPASS FLOW-THROUGH HUMIDIFIER
7 68-0272
NOTE: The furnace blower must be on for the humidifier to
operate.
4. Reset the thermostat and humidistat to a comfortable
setting for automatic operation.
TROUBLESHOOTING (TABLE 6)
Table 6. Troubleshooting Procedures.
REPLACEMENT PARTS (FIG. 6 AND TABLE 7)
Table 7. HE220A, HE260A Humidifier Replacement Parts..
Problem What To Look For What To Do
Low humidity Furnace blower not operating • Reset circuit breaker or check for blown fuse.
• Check that the furnace power is on.
• Check all external wiring connections.
• Check the humidity control setting.
• Call a professional heating contractor.
Rapid air changes. Drafts (cold air is dry
and is an added load to the humidifier
• Keep doors and windows closed.
• Close fireplace damper when not in use.
• Keep exhaust fan running time to a minimum.
• Seal around doors and windows.
High Humidity Condensation on walls • Turn humidity control and water off until condensation is
completely evaporated.
Heavy condensation on windows. • Turn humidity control down low enough to eliminate
condensation condensation caused by moisture from bathing,
mopping, cooking, etc. If moisture persists, move ventilation is
needed.
Exploded View Number Description HE220 Part Number HE260 Part Number
1 Side wall 32001612-001 32001626-001
2 Bypass side wall 32001613-001 32001627-001
3 Cover Assembly 32001611-001 32001611-002
4 PerfectFlo™ water distribution tray 32001619-001 32001630-001
5 Humidifier pad HC22A1007 HC26A1008
6 Frame 32001621-001 32001632-001
7 Drain fitting 32001615-001 32001615-001
8 Solenoid valve assembly (includes water feed
tube and nozzle)
32001639-002 32001639-002
9 Saddle valve assembly 32001616-001 32001616-001
10 Transformer (10 VA) 32001652-001 32001652-001
11 Humidistat H8908B1069 H8908B1069
12 Base insert assembly, includes no. 8 above 32001625-001 32001625-002
— Hardware Kit for Solenoid Assembly (same as
Solenoid valve assembly without the solenoid
valve)
32001752-001 32001752-001
— Current Sensing Relay 32001754-001 32001754-001
