TCS ISH3030-0140 User Manual

8
Service Fon. +49 4194 9881-188 | Fax +49 4194 9881-188 | E-Mail hotline@tcsag.de
EN
YOUR INDOOR STATION
Device overview
1 Loudspeaker
2 Call OFF button
3 LED indication (red) ring tone mute
4 Call indication (green)
5 Speech button
6 Light switch button
7 Door release button
8 Volume control
9
control key (ISW3030 | ISH3030)
Function key (ISW3130 | IVH3130)
10 Microphone
11 Handset connecting cord (Serie IVH)
12 Handset (ISH3030 | ISH3130)
LED-Display
ON tone mute is activated
Flashes call OFF deactivated, auto-
matic door release or call
diversion activated
ON call, speaking activated
blinks 3 x speech channel is busy
both LEDs
ON
ring tone selection acti-
vated
both LEDs
flashes
error indication
3
5
6
1
97
12
7
ISH3030-0140 | ISH3130-0140
4
2
10
8
1
4 3 2 6 9
11
ISW3030-0140 | ISW3130-0140

TCS ISH3030-0140 Specifications

General

Brand	TCS
Model	ISH3030-0140
Category	Intercom System
Language	English
