CABLE TV CONNECTION
Some cable TV companies offer paying Premium channels. Since these
channels’ signal is coded, normally a converter/decoder for cable TV is provided
to the customer by the cable TV company.
This converter/decoder is needed to view normally the coded channels.
To obtain specific instructions on the installation of cable TV, ask your cable TV
company.
In the following schematic is shown an example on how to connect the
converter/decoder provided by your cable TV company:
RF switch: radiofrequency socket (not
included)
2 set signal splitter:
2 sets of signal
splitters (not included)
Cable TV line: cable
TV line.
Cable TV: cable TV decoder (not
included)
Then connect the mains adaptor to a power outlet.
53
VHF/UHF IN:
VHF/UHF input
