DKC301DC SLIDING GATE OPERATOR INSTALLATION AND USER’S MANUAL
3
1. Important Safety Warning
PLEASE READ THESE IMPORTANT SAFETY RULES. Failure to comply with the following safety
rules may result in serious personal injury and/or property damage.
● ALL installation, repair, and service work must be carried out by a qualified technician.
● DISCONNECT the power cord from the MAINS before making installation, and/or any repairs
(eg welding) or removing the covers! Only experienced service personnel can remove the cover
of the control system.
● CLOSING OBSTRUCTION FORCE can be set and is adjustable on installation so that the
gate(s) reverse when obstruct with PRESSURE. This test must be repeated regular interval and
the necessary adjustments made if required.
● DO NOT operate the Gate Opener unless the Gates are in full view and free from objects such
as cars and children/people. SERIOUS PERSONAL INJURY and/or property damage can result
from failure to follow this warning.
● Children are NOT allowed to play near or operate automatic gates.
● Always keep people and objects away from the gate and its area of travel.
● The Gate should be installed on flat, level ground and can be moved and slide freely in both
directions along the entire gate length.
● Secure all easily-accessed gate opener controls in order to prevent unauthorized use
of the gate.
● In the event of power failure, use an emergency release key to operate the gate manually.
● When using the Auto close mode a PHOTOELECTRIC BEAM must be correctly fitted and
correctly tested for operation at regular intervals. EXTREME CAUTION is recommended when
using the Auto close mode. All the safety rules must be followed.
2. Technical Parameters
Tab.1
Model DKC301DC
Power supply AC240V, 50Hz
Motor DC24V 100W
Gear teeth 16 teeth
Gate moving speed 10m/min
Output Torque 10N.m
Output Speed 50rpm
Maxi. Gate Weight ≤500kg
Control board KZB21
Limit Switch Encoder limit switch
Battery charger 0.35A@24V
Standard operation with back up battery 8 times
Degree of Protection IP44
Duty Cycle S2, 20%
