9
recommended temperature range for charging the battery is
between +32°F and +113°F (0 C and +45 C). If the battery
temperature is outside of this range, the battery will not charge.
Warning! Be sure to only use the AC adapter included with your
unit. Use of other adapters will void the product warranty.
Battery Status (right LED)
Color Function
Off
Solid yellow
Solid green
Blinking yellow
On battery power
Charging on AC adapter
Fully charged on AC adapter
Battery problem during charging (temperature
out of range, defective or missing battery)
Changing the battery: The battery is designed to be quickly
changed. The unit saves enough power that if you swap the
battery within approximately one minute, it will not trigger a
reset. If the saved power runs out before the new battery is
installed, the unit will reset. This will not impact saved data,
programs or configuration, however unsaved data will be lost and
the time settings will need to be reset.
To change a battery, perform the following steps:
1. Close open applications and save data in case the battery
exchange takes too long.
2. Remove the hand strap from the unit.
3. Enter the
Replace Battery
mode
(ensures that alarms will not
wake up the unit while changing the battery). Press and hold
the
Power
key and tap
Replace Battery
. See page 12.
4. Use the supplied stylus or a small #1 Philips head screwdriver
to loosen the four screws in the battery door.
5. Remove the battery from the unit.
6. Quickly insert the replacement battery onto the unit.
7. Place the battery door over the battery, with the flat side of
the battery door at the top of the unit. Use the stylus or
screwdriver to finger-tighten the four screws.
8. Replace the hand strap.
9. Turn the unit ON to resume operation.
