Teac A-1D Service Manual

−5−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 9A09503100 KNOB 80KB448*****
2 9A09503200 KNOB 80KB451*****
3 9A09501600 FACEPLATE 75L942W0348*
4 9A09502700 ENDCAPRIGHT 76H671000000
6 9A09503000 WASHER,POWER 85A716******
7 9A09502500 BRACKET 78C284800000
8 9A09502900 KNOB,POWER 80KB450*****
9 9A09230300 ACRY 85A398******
10 9A09502800 KNOB,POWERPUSH 80KB449*****
11 9A09501700 FRONTPLATE 78C284100000
12 9A09507100 KEYPCBASSY A1DB4221****
13 9A09516700 HEATSINK 76H669000000
14£ 9A09503800 RINGTRANSFORMER[J] R93032J213**
£ 9A09503850 RINGTRANSFORMER[E] R93032E213*V
15 ‑‑‑‑‑‑‑‑‑‑ TRANSPADRUBBER
16 ‑‑‑‑‑‑‑‑‑‑ TRANSPADMETAL
17 ‑‑‑‑‑‑‑‑‑‑ NUT
18 9A09507300 ACPCBASSY[J] A1DB4227****
9A09507350 ACPCBASSY[E] A1DB4225****
19 9A09502100 REARPLATE[J] 78C2849W0487
9A09502150 REARPLATE[E] 78C2842W0349
20£ 9A09231500 BUSHING,SB4F‑4 98BSB4F4****
21£ 9A09231400 ACCORD[J] 651B2U56B24P
£ 9A09503900 ACCORD[E] 654H2E20B21S
22£ 9A09504000 ACRECEPTACLE,AS‑0715‑PQ[J] 10DAS0715PQ*
£ 9A09504050 ACRECEPTACLE,DTS‑0043[E] 10DDTS0043**
23 9A09501800 UPPERCOVER 78C284600000
24 9A09503400 KNOB 80KB453*****
25 9A09503300 KNOB 80KB452*****
26 9A09502600 ENDCAPLIFT 76H670000000
27 9A09503500 LIGHTGUIDER 85A712******
28 9A09503600 LIGHTSHIELE 85A713******
29 ‑‑‑‑‑‑‑‑‑‑ BOLT
30 9A09501900 CHASSIS,LEFT 78C284300000
31 9A09507000 AMPPCBASSY A1DB4220****
32 9A09504100 SPEAKERJACK,WTA‑510 71AWAT510***
33 9A09507200 GATHERPCBASSY A1DB4222****
34 9A09503700 FOOTCUSHION 81AD289*****
35 9A09502000 BOTTOMPLATE 78C284500000
36 9A09502200 CHASSIS,RIGHT 78C284400000
F1£ 9A09572000 FUSE,M55A/250VT[J] 2652000522*2
F1£ 9A09504500 FUSE,M52.5A/250VT[E] 265202P522*2
F2£ 9A09504300 FUSE,M51A/250VT 2652000122*2
F5,F6£ 9A09504400 FUSE,M56.3A/250VT 265206P322*2
F411£ 9A09572100 FUSE,M51.6A/250VT[J] 265201P622*2
F411£ 9A09504600 FUSE,M50.8A/250VT[E] 265200P822*2
