Teac A-1D Service Manual

AMP PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09507000 AMPPCBASSYB4220
9A09517700 AMPPCBB4220
9A09516700 HEATSINK,H‑669
9A09517600 BRACKET,C‑1307
C15£ 9A09508200 C,MEX0.1UF/250V
C70£ 9A09509000 C,ELEC1000UF/25V
C98,C99£ 9A09509400 C,ELEC10000UF/50VWHITE
D1 9A09509500 DIODE,1N914
D4‑D17 9A09237400 DIODE,1N4007
D18£ 9A09509600 BRIDGERECTIFIER,RC202
D19 9A09509500 DIODE,1N914
D20 9A09509700 ZENERDIODE,4.7V0.5W
D22£ 9A09509800 BRIDGERECTIFIER,BR102
D22 9A09509900 HEATSINK,H‑486
D32 9A09510000 ZENERDIODE,8.2V0.5W
F2,F5,F6 9A09241200 FUSEHOLDER
JP1,JP2 9A09510100 WAFER,5045‑5P
JP3 9A09510200 WAFER,3963‑2P
JP4 9A09510300 WAFER,5045‑3P
JP6 9A09510400 WAFER,3963‑3P
JP7 9A09510500 WAFER,5045‑4P
JP8 9A09244800 WAFER,5045‑2P
JP10 9A09510300 WAFER,5045‑3P
JP14 9A09510100 WAFER,5045‑5P
JP15 9A09244800 WAFER,5045‑2P
L2,L3 9A09510700 COIL,40TX0.8
L5 9A09510800 BEADCORE,3.5TX7.5MX0.8M
LTV1 9A09510900 PHOTO‑TR,LTV‑817
Q1,Q2 9A09511000 TR,2SC2235
Q3 9A09511100 TR,2SC2240
Q4‑Q9 9A09511200 TR,2SA970
Q10,Q11 9A09240700 TR,2SC3327A
Q12‑Q15£ 9A09511300 TR,2SC3421
Q16‑Q25 9A09511100 TR,2SC2240
Q26 9A09240800 TR,2SA965
Q27,Q28 9A09511600 TR,2SA1349
Q29,Q30 9A09511700 TR,2SA1145
Q31,Q32 9A09511800 TR,2SC2705
Q33,Q34£ 9A09511900 TR,2SA1358
Q35,Q36£ 9A09512000 TR,2SK1529
Q37,Q38£ 9A09512100 TR,2SJ200
Q39,Q42 9A09511200 TR,2SA970
Q43 9A09511100 TR,2SC2240
R17£ 9A09512200 R,M.O.F2W10J
R57,R62£ 9A09512200 R,M.O.F2W10J
R77,R78 9A09512800 R,METAL1/4W24K9
R81,R82 9A09512900 R,METAL1/4W620
R120£ 9A09513900 R,M.O.F2W33J
R137,R138£ 9A09514400 R,CARBON1/2W68
R141‑R144£ 9A09514500 R,CEMENT5W0.33
R152,R153£ 9A09514900 R,CARBON1/2W33
R154,R155£ 9A09515000 R,M.O.F1W8K2
R156£ 9A09512200 R,M.O.F2W10J
R161,R162£ 9A09515100 R,M.O.F2W330
R175,R176 9A09515300 NTCTHERMISTOR,220K
AMP PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
R178£ 9A09515400 R,CARBON1/2W47
RCA1‑RCA4 9A09515600 RCAJACK,HSP‑214V03
RCA6 9A09515700 M3.5JACK,HTJ‑035‑12EB
RY1 9A09515800 RELAY,V23105‑A5003‑A201
RY2,RY3 9A09515900 RELAY,G4W‑221412V
TP1‑TP4 9A09516000 COPPERCONDUCTOR
TVR1,TVR2 9A09516100 VR,SEMI‑FIXED1K
U1 9A09516300 IC,TC9163AN
U6 9A09516400 IC,JRC072
U7£ 9A09242300 IC,AN7805
U8£ 9A09516500 IC,AN7815
U9£ 9A09516600 IC,AN7915
U7‑U9 9A09529900 HEATSINK,H‑198
U12 9A09516800 IC,NE5532AN
KEY PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09507100 KEYPCBASSYB4221
9A09519300 KEYPCBB4221
D2,D3,D30 9A09509500 DIODE,1N914
IR1 9A09247100 INFERREDRECEIVER,IR‑9G
J4 9A09518100 WAFER,5045‑2P
LED1 9A09518500 LED,RT3‑634B2CS(BLUE)
LED23‑29 9A09518600 LED,L‑3XAT(YELLOW)
SW1 9A09247000 TACTSW,SKHVBK3710
U10 9A09518800 IC,BA6208
U11 9A09518900 IC,TMP87CH47U
U13 9A09519000 IC,TC74HC74AP
U14 9A09519100 IC,HD74HC14P
Z1 9A09519200 OSCILLATOR,8MHZ49US
GATHER PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09507200 GATHERPCBASSY
9A09522600 GATHERPCB
C116,C117£ 9A09520000 C,MEX0.01UF/250V
J9 9A09510300 WAFER,5045‑3P
J12 9A09520300 PHONEJACK,HTJ‑0640‑3ANI
J15,J16 9A09523300 WAFER,3963‑3P2T
JP5 9A09510100 WAFER,5045‑5P
JP11 9A09510300 WAFER,5045‑3P
P1 9A09244600 TERMNALGND,K‑15
Q40,Q41 9A09240700 TR,2SC3327A
SW1£ 9A09521600 SW,POWERSDDFA3117UTV8
SW3 9A09521700 SW,ROTATEEC16B24202
U2 9A09521800 IC,OPA2604
U3 9A09516800 IC,NE5532AN
U4 9A09521900 IC,JRC4556
U5 9A09522000 IC,AD712
VR1 9A09522200 VR,25KMNRK163121A105
VR2 9A09522300 VR,50KAX2RK18112MC
VR3,VR4 9A09522400 VR,100KBX2RK16F121A400
VR5 9A09522500 VR,100KAX2RD163121R033
−8−
