MAIN PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09157400 MAINPCBASSY
9A09188400 MAINPCB
9A09192100 HEATSINK,AE338
9A09192200 HEATSINK,520‑R
9A09192300 SCREW,MACHINEMS/PH3X8
9A09192400 NUT,3MMHEATSINK
C127‑C129£ 9A07084600 C,ELECT100UF/50VM
C130£ 9A09190800 C,ELECT4700UF/25VM
C132,C133£ 9A09190900 C,ELECT2200UF/25VM
C148£ 9A02684500 C,ELECT470UF/16VM
CN101 9A00436800 PLUG,5P
CN102 9A00188000 PLUG,6PPHV
CN103 9A08899500 PLUG,16PFFC
CN104 9A09189700 PLUG,11P
CN105 9A00436800 PLUG,5P
CN106 9A09189800 PLUG,7P
CN108 9A09189900 PLUG,3P
CN110 9A09190000 PLUG,2P
CN501 9A00436800 PLUG,5P
D101‑D108£ 9A06853300 DIODE,1A3‑I
D109 9A09190100 ZENERDIODE,30V1/2W
D110 9A06853900 ZENERDIODE,MTZJ5.1B‑T‑77
D111,D112 9A06853400 DIODE,1SS133‑T‑77
D113,D114£ 9A06853300 DIODE,1A3‑I
D115 9A06853900 ZENERDIODE,MTZJ5.1B‑T‑77
IC101 9A09188500 IC,UPD63711GC‑8EU
IC102 9A09188600 IC,BA5813FM
IC103 9A09188700 IC,UPD789026GB‑A59‑8ES
IC104£ 9A09188800 IC,KA7805
IC105£ 9A09188900 IC,KA7808
IC106£ 9A06854500 IC,NJM7805FA
IC107£ 9A09189000 IC,NJM79L06A
IC108 9A09189100 IC,PST600D
IC109 9A09189200 IC,TC74HC00AP
IC110 9A09189300 IC,BA7042
IC501 9A09189400 IC,NJM2068D
IC502 9A09189500 IC,NJM4558D
JK101 9A09189600 JACK,RCA1P
JK501 9A06859100 JACK,RCA2P
MH101 9A07274100 TERMINAL,GND
P101,P102 9A07087600 POTENTIOMETER,10KB
Q101 9A08895000 TR,2SA933AS‑TP
Q102 9A08895100 TR,2SB1375
Q501‑Q503 9A06857000 TR,2SD1936‑T‑AC
R122‑R124£ 9A09190400 R,CARBON4.7KJA1/2W
RT101 9A09190600 THERMISTOR,2.0K
T101 9A09192000 TRANS,PULSE
X101 9A02264500 CRYSTAL,16.9344MHZ
X301 9A08900500 RESONATOR,CERAMIC5.00MHZ
DISPLAY PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09157500 DISPLAYPCBASSY
9A09157600 DISPLAYPCB
9A07079700 PAD,FL
CN301 9A09192600 PLUG,11P
CN302 9A09192700 PLUG,16P
D303‑D308 9A06853400 DIODE,1SS133‑T‑77
FL301 9A07086600 FLT,11‑BT‑132GK
SW301‑312 9A08467800 SWITCH,TACT,SKHHANA010
KEY SW PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09187200 KEYSWPCBASSY
9A09192900 KEYSWPCB
9A07079500 SPACER
CN303 9A09192700 PLUG,16P
CN306 9A07087000 PLUG,4P
D302 9A07076000 LED,TLOE262
Q301,Q302 9A06856900 TR,2SA933AS‑TP‑R
SW313‑326 9A08467800 SWITCH,TACT,SKHHANA010
U301 9A06847600 IC,GP1U281X
PITCH CON PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09187300 PITCHCONPCBASSY
9A09193000 PITCHCONPCB
9A07078600 BRACKET‑E,LED
9A07079400 SPACER
CN307 9A00436900 PLUG,3P
CN308 9A07087000 PLUG,4P
D303 9A07076000 LED,TLOE262
SW327 9A09193100 SWITCH,TACT
VR301 9A07082800 VR,ROTARY50KB
H.P. PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
9A09187400 H.P.PCBASSY
9A09193200 H.P.PCB
IC401 9A09193300 IC,M5218AP
JK401 9A07081200 JACK,H.P.
L401 9A07082500 COIL
L402 9A07082500 COIL
VR401 9A07082700 VR,ROTARY50K
−10−
