−6−
EXPLODED VIEW-2 (CD93F8NDT)
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 9A07071300 SWITCHPCBASSY 1EA0B10A98100
3 9A07072300 CHASSIS,FRAME 1EA2311A06600
4 9A07071400 PLATE,MAGNET 1EA2336A05300
5 9A07071500 LEFTRAILASSY 1EA0363A00100
6 9A07071600 RAIL,RIGHT 1EA2363A00300
8 9A07071800 SUPPORT,MAGNET 1EA2413A01700
9 9A08438700 CUSHION,RUBBER CEC2443000100
10 9A08438800 CUSHION,RUBBER CEC2443000101
11 9A07072100 HOLDER,MAGNET 1EA2451A09000
12 9A07072200 SHEET 1EA2462A13200
13 9A07072400 GEAR,LOADING 1EA2511A10900
14 9A07072500 GEAR,LIFTER 1EA2511A11000
15 9A07072600 GEAR,IDLER,A 1EA2511A11100
16 9A07072700 GEAR,IDLER,B 1EA2511A11200
17 9A07072800 PULLEY,MOTOR 1EA2523A01700
18 9A07072900 PULLEY,GEAR 1EA2524A01600
19 9A07073000 BELT,SQUARE 1EA2563A02200
20 9A02677600 MAGNET,DISCCLAMP 1EA2641A01300
21 9A08438600 LIFTER,MECHA CEC2713000700
22 9A07073200 SLIDE,LIFTER 1EA2741A01300
23 9A07073300 TABLE,LOADING 1EA2761A00700
24 9A03303300 MOTOR,3.0V 1EA4M10A02100
30 5760707700 SCREW,B‑TITESEMSM3X10 13124201283000
31 9A07073500 SCREW,S‑TPGBIN2.6X8 SFBDN268R0SE‑
31‑02 9A09093000 MECHASSY,DA11T3CN 13933102
31‑40 9A07070800 BRACKET CEC2322001300
31‑41 9A07070900 SHEET,MECHA CEC2462011200
31SA1 9A07071100 SCREW,S‑TPGBIN3X8 SFBDN308R0SE‑
32 9A07073600 SCREW,S‑TPGPAN+FLG2X6 SFBPY206R0SE‑
33 9A07073700 SCREW,PAN+SW1.7X3.5 SM2PS173R5SE‑
34 9A07073800 SCREW,SPECIAL SGXEA00201‑‑‑
35 9A07071100 SCREW,S‑TPGBIN3X8 SFBDN308R0SE‑
9A08632700 WIRE,JUMPER,16P CEC4W30009700
