TASCAM MD-CD1 RS-232C Protocol Specification
16 TEAC Corporation
FADE IN/OUT TIME PRESET
Specifies the fade-in/out time used for the fade-in/out recording function of the controlled device.
A range of 1 to 30 seconds can be specified.
A return command is returned only if Sense [FF] is specified.
If Sense [FF] is specified, the data is two bytes.
Command 2E
Machine ID 0
Data 4 bytes or 2 bytes
Data
1
Data
2
Data
3
Data
4
Description Remarks
0 0
1
IN Time
OUT Time
N1 N2 Preset Time N1：Tens digit, N2： Ones digit
F F … Sense Requests that the preset content be returned.
・ If data outside the specified operating range is received, the controlled device will transmit
ILLEGAL[F2].
Return FADE IN/OUT TIME RETURN [AE]
DIGITAL VOLUME DATA PRESET
Specifies the digital volume of the controlled device.
The range that can be set is -54dB～+18dB and -∞dB.
You can set the -54.0dB～-24.0dB range is 6.0dB steps, the -24.0dB～-12.0dB range in 4.0dB steps,
the -12.0dB～-6.0dB range is 2.0dB steps, the -6.0dB～+6.0dB range in 0.5dB steps, and the +6.0dB
～+18.0dB range in 1.0dB steps.
A return command is returned only if Sense [FF] is specified.
If Sense [FF] is specified, the data is two bytes.
Command 2F
Machine ID 0
Data 4 bytes or 2 bytes
Data
1
Data
2
Data
3
Data
4
Description Remarks
0
1
Positive value
Negative value
N2 N3 N1
Preset Level
N1 ： Tens digit, N2： Ones digit, N3： First
decimal place
Example) 6011: -16.0dB
A A A A Preset -∞dB
F F … Sense Requests that the preset content be returned
・ If data outside the specified operating range is received, the controlled device will transmit
ILLEGAL[F2]
Return DIGITAL VOLUME DATA RETURN [AF]
AUTO CUE SELECT
Specifies the auto cue mode setting of the controlled device.
A return command is returned only if Sense [FF] is specified.
The AUTO CUE LEVEL setting is made by the command "AUTO CUE LEVEL PRESET [20]."
Command 30
Machine ID 0
Data 2 bytes
Data 1 Data 2 Description Remarks
0 0 Auto Cue Off
0 1 Auto Cue On
F F Sense Requests that the preset content be returned.
