Teac D-70 - Page 13

DIGITAL PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
E95133500A PCBASSY,DIGITAL
E90133500C PCB,DIGITAL
E0071650 SOCKET,IC30‑0803‑S4
* M0052230 HEATSINK,OSH‑1525‑SP
* 5780023008 SCREW,BPA3X8NB
* 5780222606 SCREW,FLATM2.6X6NB
C106 C0036264 CE,47UF10VMSVP
C107 5260572920 CE,1.0UF50VMECEV
C110 C0036264 CE,47UF10VMSVP
C112 C0036264 CE,47UF10VMSVP
C113 5260572920 CE,1.0UF50VMECEV
C116 C0036264 CE,47UF10VMSVP
C118 C0036264 CE,47UF10VMSVP
C119 5260572920 CE,1.0UF50VMECEV
C124,C125 C0036264 CE,47UF10VMSVP
C127 C0036264 CE,47UF10VMSVP
C130 C0036264 CE,47UF10VMSVP
C131 C0030704 CE,47UF16VMECEV
C134 C0036264 CE,47UF10VMSVP
C139 C0036264 CE,47UF10VMSVP
C144 C0036264 CE,47UF10VMSVP
C157 C0030704 CE,47UF16VMECEV
C158 C0036264 CE,47UF10VMSVP
C161 C0036264 CE,47UF10VMSVP
C237 C0036264 CE,47UF10VMSVP
C240 C0025384 CE,100UF16VM
C243 C0030704 CE,47UF16VMECEV
C271‑C281 C0036264 CE,47UF10VMSVP
D101‑D104 13411596 DIODE,IMN10
D105 S0035214 DIODE,HVC376B‑TRF
J101,J102 * 5334078400 CONNECTOR,XLM‑3‑31PCV
J103‑J105 E00353701A JACK,RCA1PWHITENICKING
L101,L102 5286033520 CHC,4.7UHK(LAP2T)
P101 * 5336303400 CONNPLUG,B4B‑EH(WHT)
P102 * E0070160 CONNECTOR,FMN28BTK‑A
P103 * E0070170 CONNECTOR,FMN33BTK‑A
P104 * 5336249700 CONNPLUG,B07B‑PH‑K‑SW
P105 * 5336303600 CONNPLUG,B6B‑EH(WHT)
P106 * 5336250300 CONNPLUG,B13B‑PH‑K‑SW
P107 * 5336249600 CONNPLUG,B06B‑PH‑K‑SW
P108 * 5336303200 CONNPLUG,B2B‑EH(WHT)
P109 * 5336303600 CONNPLUG,B6B‑EH(WHT)
Q101 S0022044 TR,DTC114EUA‑T106
Q102 S0047644 TR,DTB113EK‑T146
S101 E0031064 SW,SLIDECHS‑02TA
U101,U102 S0046390 IC,GP1FA551RZ
U103 S0039444 IC,HD26C32AFPEL
U104,U105 S0049413 IC,CS8415A‑CZ
U106 S0019640 IC,TC74VHC157F
U107‑U109 S0020700 IC,TC74VHCU04F
U110 S0047794 IC,TC74VHCT08AF
U111,U112£ S0038210 IC,NJM317F
U113£ S0047403 IC,BA05FP
U114 S0025614 IC,TC74VHCT541AFEL
U115 S0047794 IC,TC74VHCT08AF
DIGITAL PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
U116 S0046423 IC,TC74VHC125F
U117 S0047794 IC,TC74VHCT08AF
U118 5220121000 IC,HD74HC540FPEL
U119 S0046400 IC,GP1FA551TZ
U120 S0027400 IC,TC74VHC32F
U121 S0046433 IC,PMD200
U122 S0046903 IC,XC2S200‑5PQ208C
U123 S0046333 IC,XC2S30‑5VQ100C
U124 S0046373 IC,W981216BH‑8H
U125 S00481500D IC,MPUD‑70V1.04
U126 5220116400 IC,HD74HC138FP
U127 S0025614 IC,TC74VHCT541AFEL
U128 S00474100A IC,512DIVPLDD‑70
U129 5220123500 IC,MC74HC4046AF‑FR1
U130 S0033414 IC,M93C46‑MN6T
U131 S00464900B IC,RDOTDFOTPROM
U132 S00465000A IC,RAMCONTROLOTPROM
U135 S0020334 IC,TC74VHC04
U136 S0037124 IC,TC74LCX541F(EL)
U137 S0025614 IC,TC74VHCT541AFEL
U138 S0037124 IC,TC74LCX541F(EL)
U139‑U143 S0025614 IC,TC74VHCT541AFEL
U144 S0020344 IC,TC74VHC541
U145 S0048103 IC,TC74VHC00FT
X101 E0048054 RESONATOR,5MHZEFOS
ANALOG PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
E95133600A PCBASSY,ANALOG
E90133600B PCB,ANALOG
* 5780222606 SCREW,FLATM2.6X6NB
C301 C0007510 CE,47UF16VMSA
C308 5260463120 CE,100UF16VMAU
C310 C0007510 CE,47UF16VMSA
C323 5260462720 CE,47UF25VMAU
C329 C0007510 CE,47UF16VMSA
C336,C436 C0007510 CE,47UF16VMSA
C338,C438 C0007510 CE,47UF16VMSA
C341,C441 C0007510 CE,47UF16VMSA
C342,C442 5260461820 CE,22UF25VMAU
C343,C443 5260463120 CE,100UF16VMAU
C344,C444 5260462720 CE,47UF25VMAU
C346,C446 C0007510 CE,47UF16VMSA
C348,C448 C0035340 CE,100UF16VMSA
C351,C451 C0035340 CE,100UF16VMSA
C353,C453 C0007510 CE,47UF16VMSA
C355,C455 C0007510 CE,47UF16VMSA
C358,C458 C0007510 CE,47UF16VMSA
C359,C459 5260461820 CE,22UF25VMAU
C360,C460 5260463120 CE,100UF16VMAU
C361,C461 5260462720 CE,47UF25VMAU
C363,C463 C0007510 CE,47UF16VMSA
C365,C465 C0035340 CE,100UF16VMSA
−13−
