Teac D-70 - Page 14

ANALOG PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
C368,C468 C0035340 CE,100UF16VMSA
C370,C470 C0035340 CE,100UF16VMSA
C374,C474 C0035340 CE,100UF16VMSA
C376,C476 5260463820 CE,220UF25VMAU
C378,C478 5260463820 CE,220UF25VMAU
C383,C483 5260463820 CE,220UF25VMAU
C385,C485 5260463820 CE,220UF25VMAU
C390,C490 5260463820 CE,220UF25VMAU
C392,C492 5260463820 CE,220UF25VMAU
C398,C498 5260463820 CE,220UF25VMAU
C402,C404 C0007510 CE,47UF16VMSA
C406,C408 C0007510 CE,47UF16VMSA
C410,C412 C0007510 CE,47UF16VMSA
C414,C416 C0007510 CE,47UF16VMSA
C418,C420 C0007510 CE,47UF16VMSA
C428 5260463120 CE,100UF16VMAU
C900,C950 5260463820 CE,220UF25VMAU
C913 5260462720 CE,47UF25VMAU
C920,C970 5260461520 CE,10UF25VMAU
C921,C971 5260461520 CE,10UF25VMAU
C922,C972 C0035340 CE,100UF16VMSA
C924,C974 C0035340 CE,100UF16VMSA
C927,C977 C0035340 CE,100UF16VMSA
C959 5260463120 CE,100UF16VMAU
C981 5260462720 CE,47UF25VMAU
D301‑D305 5224016420 DIODE,S5688G
D401‑D405 5224016420 DIODE,S5688G
J301 E00353701A JACK,RCA1PWHITENICKING
J304,J404 5334078800 CONNECTOR,XLM‑3‑32PCV
J401 E00353801A JACK,RCA1PREDNICKING
K301‑K305 5290015600 RLY,A‑12W‑K
K401‑K405 5290015600 RLY,A‑12W‑K
L301‑L307 5286033520 CHC,4.7UHK(LAP2T)
L314‑L329 5286033520 CHC,4.7UHK(LAP2T)
L414‑L429 5286033520 CHC,4.7UHK(LAP2T)
P301 E0070170 CONNECTOR,FMN33BTK‑A
P302 * 5336303300 CONNPLUG,B3B‑EH(WHT)
P303 * 5336309300 CONNPLUG,B3B‑EH‑K(BLK)
P304 * 5336305300 CONNPLUG,B3B‑EH‑R(RED)
P305 * 5336307300 CONNPLUG,B3B‑EH‑Y(YEL)
P306 * 5336303400 CONNPLUG,B4B‑EH(WHT)
P307 * 5336303200 CONNPLUG,B2B‑EH(WHT)
P308 * 5336303600 CONNPLUG,B6B‑EH(WHT)
P312 * 5336249600 CONNPLUG,B06B‑PH‑K‑SW
Q301‑Q305 5232255620 TR,DTC114ESA
Q401‑Q405 5232255620 TR,DTC114ESA
R310‑R312 R0108861 RN,1/4W8.2KOHMF
R344,R444 R0108721 RN,1/4W2.2KOHMF
R345,R445 R0108721 RN,1/4W2.2KOHMF
R346,R446 R0108871 RN,1/4W9.1KOHMF
R347,R447 R0108871 RN,1/4W9.1KOHMF
R348,R448 R0108871 RN,1/4W9.1KOHMF
R349,R449 R0108871 RN,1/4W9.1KOHMF
R350,R450 R0108861 RN,1/4W8.2KOHMF
R351,R451 R0108841 RN,1/4W6.8KOHMF
ANALOG PCB ASSY
REF.NO. PARTSNO. DESCRIPTION
R352,R452 R0108841 RN,1/4W6.8KOHMF
R353,R453 R0108811 RN,1/4W5.1KOHMF
R354,R454 R0108841 RN,1/4W6.8KOHMF
R355,R455 R0108841 RN,1/4W6.8KOHMF
R356,R456 R0108811 RN,1/4W5.1KOHMF
R357,R457 R0108841 RN,1/4W6.8KOHMF
R358,R458 R0108841 RN,1/4W6.8KOHMF
R359,R459 R0108811 RN,1/4W5.1KOHMF
R362,R462 R0108641 RN,1/4W1.0KOHMF
R363,R463 R0108641 RN,1/4W1.0KOHMF
R364,R464 R0108641 RN,1/4W1.0KOHMF
R365,R465 R0108641 RN,1/4W1.0KOHMF
R366,R466 R0108801 RN,1/4W4.7KOHMF
R367,R467 R0108801 RN,1/4W4.7KOHMF
R368,R468 R0108641 RN,1/4W1.0KOHMF
R369,R469 R0108641 RN,1/4W1.0KOHMF
R370,R470 R0108641 RN,1/4W1.0KOHMF
R371,R471 R0108641 RN,1/4W1.0KOHMF
R372,R472 R0108561 RN,1/4W470OHMF
R373,R473 R0108561 RN,1/4W470OHMF
R374,R474 R0108561 RN,1/4W470OHMF
R375,R475 R0108631 RN,1/4W910OHMF
R381,R481 R0108631 RN,1/4W910OHMF
R382,R482 R0108631 RN,1/4W910OHMF
R410‑R412 R0108861 RN,1/4W8.2KOHMF
RA301‑RA304 R0093170 RESARRAY,RGLE4X103J
U301 S0019610 IC,TC74VHC153F
U302 S0024914 IC,TC74VHC139F(EL)
U303‑U305 S0046863 IC,ISO150AU
U306 S0047004 IC,PC3Q66Q
U311 S00472800A IC,CLOCKPLDD‑70
U312 S0020344 IC,TC74VHC541
U321,U421 S0037410 IC,PCM1704U
U322,U422 S0037410 IC,PCM1704U
U323‑U325 S0047610 IC,OP184FP
U326‑U328 5220448200 IC,NJM2114D
U329,U429 S0025780 IC,OPA2132PA
U330 S0019590 IC,TC74VHC08F
U333,U433 S0049670 IC,OPA627AP
U334 S0020344 IC,TC74VHC541
U335 S0025614 IC,TC74VHCT541AFEL
U336 S0020344 IC,TC74VHC541
U337 S0020344 IC,TC74VHC541
U338 13444936 IC,74HC14FP
U339£ S0047403 IC,BA05FP
U340 13444936 IC,74HC14FP
U423‑U425 S0047610 IC,OP184FP
U426‑U428 5220448200 IC,NJM2114D
VR303,VR403 5280241000 VR,SEMI‑FIXED4.7KB
X301 E0071060 CRYSTALOSC,22.5792MHHC
X302 E0070740 CRYSTALOSC,24.576M50PPM
X303 E0071080 CRYSTALOSC,16.3840MHHC
−14−
