Teac D-70 - Page 15

FRONT PCB ASSY Part of GATHER PCB A ASSY
REF.NO. PARTSNO. DESCRIPTION
E95133700A PCBASSY,FRONT
E90133700A PCB,FRONT
* M00070302A SPACER,LEDLH‑3L=2
* M0141680 HOLDER,LEDLF‑8
M00070300A SPACER,LEDLH‑3L=6
M0141690 HOLDER,LEDLF‑12
M00539300A HOLDERASSY,FL
C804 5260462620 CE,47UF16VMAU
D805‑D814 S0036900 LED,L‑934MBTBLUE
FL801 E00694100A ELCTRNRAYDSPL
P801 * 13121317 CONNECTOR,S6B‑EH
P802 * E0070150 CONNECTOR,FMN28STK
P803 * 5336287900 CONNPLUG,S9B‑PH‑K‑SW
Q801 5232254720 TR,DTA114ESA
Q805‑Q814 5232255620 TR,DTC114ESA
Q815 5232254720 TR,DTA114ESA
S803‑S805 5302108600 SW,TACTSKHVBE
S806 E0069030 ENCODER,EC12E2460803
U801 S0018723 IC,M66004FP
U802 S0046410 IC,RPM7138‑H4
TOGGLED PCB ASSY Part of GATHER PCB A ASSY
REF.NO. PARTSNO. DESCRIPTION
E95133800A PCBASSY,TOGGLED
E90133800A PCB,TOGGLED
M00070300A SPACER,LEDLH‑3L=6
* M0141690 HOLDER,LEDLF‑12
D801‑D804 S0036900 LED,L‑934MBTBLUE
P804 * 5336287900 CONNPLUG,S9B‑PH‑K‑SW
Q802‑Q804 5232255620 TR,DTC114ESA
S801 13223118 SW,TOGGLE8A1011
S802 E0022170 SW,TOGGLE8A1021
WORD PCB ASSY Part of GATHER PCB A ASSY
REF.NO. PARTSNO. DESCRIPTION
E95134400A PCBASSY,WORD
E90134400A PCB,WORD
* 13180156 TERMINAL
C909 C0007510 CE,47UF16VMSA
J302,J303 * E0000760 CONNECTOR,BNCBCJ‑FPLHA
L330,L331 14727479 INDUCTOR,FERRITEBEADS
P311 5336303400 CONNPLUG,B4B‑EH(WHT)
U331 5220102000 IC,SN74S140NS
BAL SW PCB ASSY Part of GATHER PCB A ASSY
REF.NO. PARTSNO. DESCRIPTION
E95133900A PCBASSY,BALSW
E90133900A PCB,BALSW
P310 * 13121313 CONNECTOR,S2B‑EH
S301 13223118 SW,TOGGLE8A1011
PWR DIGI PCB ASSY Part of GATHER PCB B ASSY
REF.NO. PARTSNO. DESCRIPTION
E95134000A PCBASSY,PWRDIGI[US,C]
E95134050A PCBASSY,PWRDIGI[E]
E90134000A PCB,PWRDIGI
* 5555590000 EARTHPLATEA
* E0034560 CLIPFUSE,H0446
* M00350800A HEATSINK,OSH‑2435‑SPL
* 5780023008 SCREW,BPA3X8NB
C501‑C504£ 5263341300 C,POLY100PF630VG
C505 5263341300 C,POLY100PF630VG
C506£ C0033090 CE,6800UF50VMX‑PRO
C508 5260531420 CE,100UF20VMSA
C515£ 5260463420 CE,100UF50VMAU
C516£ 5260462920 CE,47UF50VMAU
C517,C518 5260462920 CE,47UF50VMAU
C519 5260461320 CE,3.3UF50VMAU
C520 5260461520 CE,10UF25VMAU
C523 5263341300 C,POLY100PF630VG
C524 5260462720 CE,47UF25VMAU
C528‑C531£ 5263341300 C,POLY100PF630VG
C532£ C0033090 CE,6800UF50VMX‑PRO
C534 5260531420 CE,100UF20VMSA
D501‑D504£ S0015461 DIODE,FE5D
D505 5224016420 DIODE,S5688G
D507£ 5224016420 DIODE,S5688G
D508 5224592821 ZENERDIODE,RD33ESB1
D509 5224584921 ZENERDIODE,RD5.1ESB2
D511 5224016420 DIODE,S5688G
D513‑D516£ S0015461 DIODE,FE5D
F501,F502£ E0077810 FUSE,2.0AT‑LAG[US,C]
F501,F502£ E0077630 FUSE,2.0AT‑LAG[E]
P501 * 5336303700 CONNPLUG,B7B‑EH(WHT)
P502 * 5336303600 CONNPLUG,B6B‑EH(WHT)
P503 * 5336303300 CONNPLUG,B3B‑EH(WHT)
P504 * 5336305300 CONNPLUG,B3B‑EH‑R(RED)
P505 * 5336303400 CONNPLUG,B4B‑EH(WHT)
P506 * 5336303200 CONNPLUG,B2B‑EH(WHT)
Q501 5230781120 TR,2SC1740SLN
Q503£ 5230509100 TR,2SB562C
R501,R502 R0102351 RN,1/4W1.0KOHMFCSN2C
R505 R0102351 RN,1/4W1.0KOHMFCSN2C
R506 R0102471 RN,1/4W3.3KOHMFCSN2C
R507 R0102511 RN,1/4W4.7KOHMFCSN2C
U501,U502£ S0047390 IC,BA05T
U503 5220051800 IC,TC74HC04AP
−15−
