PWR ANA PCB ASSY Part of GATHER PCB B ASSY
REF.NO. PARTSNO. DESCRIPTION
E95134100A PCBASSY,PWRANA[US,C]
E95134150A PCBASSY,PWRANA[E]
E90134100A PCB,PWRANA
* 5555590000 EARTHPLATEA
* E0034560 CLIPFUSE,H0446
* M00350800A HEATSINK,OSH‑2435‑SPL
* 5780023008 SCREW,BPA3X8NB
C601‑C608£ 5263341300 C,POLY100PF630VG
C609,C610 5263341300 C,POLY100PF630VG
C611£ C0038240 CE,3900UF25VMMV‑AX
C614,C615£ C0038240 CE,3900UF25VMMV‑AX
C618£ C0038240 CE,3900UF25VMMV‑AX
C621,C622 5260531420 CE,100UF20VMSA
C625,C626 5260531420 CE,100UF20VMSA
C629,C630 5260531420 CE,100UF20VMSA
D601‑D608£ S0015461 DIODE,FE5D
F601‑F604£ E0077810 FUSE,2.0AT‑LAG[US,C]
F601‑F604£ E0077630 FUSE,2.0AT‑LAG[E]
P601 5336303600 CONNPLUG,B6B‑EH(WHT)
P602 5336307300 CONNPLUG,B3B‑EH‑Y(YEL)
P603 5336305300 CONNPLUG,B3B‑EH‑R(RED)
P604 5336309300 CONNPLUG,B3B‑EH‑K(BLK)
R601,R602 R0102351 RN,1/4W1.0KOHMFCSN2C
U601£ 5220454600 IC,LM7812CT
U602£ 5220454800 IC,LM7912CT
U603,U605£ 5220454500 IC,LM7805CT
U604,U606£ 5220454700 IC,LM7905CT
PWSW PCB ASSY Part of GATHER PCB B ASSY
REF.NO. PARTSNO. DESCRIPTION
E95134200A PCBASSY,PWSW
E90134200A PCB,PWSW
C701£ E0022570 SPKKILLER,0.0047UF250V
L701,L702£ 5292806300 NOISEFILTER,FKOB16MH13
P701‑P703 5336376200 CONNPLUG,B2P3‑VH
SW701£ 5300054700 SW,PUSHSDDLD1166A
INLET PCB ASSY Part of GATHER PCB B ASSY
REF.NO. PARTSNO. DESCRIPTION
E95134300A PCBASSY,INLET
E90134300A PCB,INLET
P704 5336376200 CONNPLUG,B2P3‑VH
PG701£ 5292813500 EMIFLTR,06ME36A115/250V
−16−
