SCART 、AV、S-VIDEO port
SCARGT
Lose color,
color cast
All no signal
System setting
not correct,
reset system
Check CON11SCART
RGB input network
Does software work?
Is U13（ MSD306PT）RGB
Input signal normal?
Y N
Does SCART
socket
touch normal?
Is AV,S-VIDEO
Input signal normal?
Change
external
signal source
N
Y
Check the connection network
between U13 and the input
port whether correct or not
Check U13and it’s
external circuit
N Y
Check and repair
the concerned
Input network
Picture 9 Function Unit
（SCART、AV、S-V）
