7
Fixing the stand
3. Warnings.
1. The parts
needed for installing the stand (supplied)
TV set
Stand
Screws(supplied)
4 x ST4 x 16F
2. How to install the Stand?
Back
Front
Front
Top View
Front
Before installing the stand, please check that
you have all of the parts and that there is no
visible damage. If a part is missing or appears
damaged, please contact customer service.
Place the TV face down on a soft and flat surface (blanket, foam, cloth, etc.) to prevent any damage to the TV.
Put the Stand to the neck of the TV set as shown below.
1. Before you put on the stand, please make sure the direction is correct
as shown below.
2. When you are putting on the stand, please make sure the neck of the
TV set is in the correct position and attached tightly.
If you do not attach the stand correctly, it will make the TV unstable
and may tip over.
Attach the stand with the supplied screws.
When attaching the stand, make sure the screws
are attached tightly.
If the screws do not attach tightly, it will lead the TV
to be unstable or may even tip over.
a. It can not be tilted to the front or back as
shown below. Doing so may damage the
stand.
b. It can not be tilted to the right or left as shown below.
Doing so may damage the stand.
