7
ENGLISH
Type
Coaxial two-way speakers
with bass reflex port (rear)
Loudspeaker units
Low-frequency 13cm (5") paper cone
High-frequency 2.5cm (1") titanium dome
Rated input 50 W
Maximum input 100 W
Impedance 6 Ω
Output sound pressure level 86 dB (1 W, 1 m)
Playback frequency range 50–50,000 Hz
Crossover frequency 3.5 kHz
Cabinet volume 6.2 liters
External dimensions (W × H × D)
184 × 260 × 229 mm (7 1/4" × 10 1/4" × 9 1/8")
(not including terminal protrusions or spikes)
Weight 4.4 kg/speaker (9 3/4 lb)
Included accessories
Speaker cables (2 m or 6 1/2 ft) × 2
Screw spikes × 6
Washers × 6
Nuts × 6 (already attached to screw spikes)
Spike bases × 6
Cleaning cloth × 1
Owner’s Manual (including warranty) (this document) × 1
o In order to improve the product, specifications and appearances might be changed without notice.
o Weight and dimensions are approximate.
o Illustrations in this Owner’s Manual might differ in part from the actual product.
Specifications
