−7−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 9A09229700 FACEPLATE 75L837W0248*
2 9A09230500 WASHER,POWERKNOB 85A637******
3 9A09231000 WASHER 85A638******
4 9A09230400 POWERKNOB 80KB431*****
5 9A09230300 ACRY 85A398******
6 9A09230600 PUSHKNOB 80KB432*****
7 9A09230200 ACRY 85A636******
8 9A09230700 PUSHKNOB 80KB433*****
9 9A09230800 PUSHKNOB 80KB434*****
10 9A09230900 PUSHKNOB 80KB435*****
11 9A09229800 SUBPLATE 78C266000000
12 9A09233400 KEYPCBASSY TR670B3851**
13 9A09231200 FEET 81AD287*****
14 9A09230000 BOTTOMPLATE 78C266200000
15 9A09231700 BRACKER,U‑TYPE 78C206000000
16 9A09233500 TRANSFORMERPCBASSY TR670B3852**
17 9A09230100 UPPERCOVER 78C266300000
18 9A09233300 MAINPCBASSY TR670B3850**
19 9A09233600 SELECTSWPCBASSY TR670B3853**
20£ 9A09231500 BUSHING 98BSB4F4****
21£ 9A09231400 ACCORD 651B2U56B24P
22 9A09231300 HOLER,ANT 85A271******
23 9A09229900 REARPLATE 78C2661W0245
F1,F2£ 9A09231900 FUSE0.5A/250VT 265200P521TQ
F3£ 9A09232000 FUSE0.1A/250VT 265200P121TQ
INCLUDED ACCESSORIES
REF.NO. PARTSNO. DESCRIPTION REMARKS
9A08814500 OWNER'SMNL,E/F 9904TR670***
9A09234200 REMOTECONTROLUNIT 62CR19C10001
9A09234300 BATTERY 250027******
9A09233800 LOOPANT 64LA75******
9A09233900 TVDIPOLEANT 64T0001*****
9A09234000 ANTADAPTER 68AJ20092046
