404M 4040 505M 5050
Width - chutes closed 1.98m 1.98m 1.98m 1.98m
Width - operating 2.06m 2.48m 2.13m 2.48m
Operating width with Giraffe Chute 2.28m 2.64m 2.28m 2.76m
Length (1.55m drum fitted) 2.36m 2.36m 2.36m 2.36m
Height lowered (1.55m drum fitted) * 2.18m 2.18m 2.44m 2.44m
Drum diameter 1.57m 1.57m 1.83m 1.83m
Upper chute discharge height * 1.14m 1.14m 1.14m 1.14m
Lower chute discharge height * 0.4m 0.4m 0.4m 0.4m
Straw Giraffe chute height * 1.84m 1.84m 1.84m 1.84m
Unladen weight (1.55m drum fitted) 904kg 811kg 970kg 877kg
Minimum tractor power requirement 37kW 45kW 37kW 45kW
Sound power level 93db A 93db A 93db A 93db A
1.0 SPECFICIATIONS
* Heights listed are with the machine on the ground. When operating these heights can be increased by up to 1m
depending on the tractor to which the machine is attached.
2
1.1 Basic machine specifications
Specifications
Overall machine width
2.82 m
Minimum tractor power requirement 90kW
PTO Speed 1000 rpm
Additional weight over basic machine (including hydraulic oil) 420kg
Sound power level 130 dB A
Maximum hydraulic oil pressure 220 bar (3190 psi)
Hydraulic oil specification ISO HV46
Hydraulic oil tank capacity
150 Litres
(33) gallons
1.2 Booster fan specifications
