Teagle Tomahawk 8500 Instruction Book

10
Please read instruction book
before using the machine
Tighten wheel nuts to setting in
operators handbook
Beware thrown objects
keep your distance
Allow rotor to stop before removing
blockage with tool provided
Direction of rotation and
speed of PTO input shaft
Blockage removal tool
Tractor Control Desk Panel
Remote Tailgate Control Box Panel
High rotor speed
Low rotor speed
2. EXPLANATION OF PICTOGRAMS
Bed chain speed
Raise giraffe
chute deflector
Rotate giraffe
clockwise
Rotate giraffe
anti-clockwise
Lower giraffe
chute deflector
Bed chain forward Bed chain reverse
Power on Power off
Giraffe chute selector
or
long chop
RH chute selector
or
short chop
Lower tailgate
Lower RH chute
Raise RH chute
Raise tailgate
Bed chain reverse
Bed chain forward
Raise tailgate
Lower tailgate
Hold to run button
(must be depressed
to work any other
function)
On light
Bluetooth on
Flashing = connecting
