Ref. Description Part No. Qty. Associated Components Part No. Qty.
7 Swivel Chute Base SC4221 1
8 Chute Ram CYL1084 1 Pivot Bush - Deflector SC3297 1
Bolt M12 x 80 FAS9688P 1
Pivot Bush - Ram Body SC4048 1
Bolt M12 x 90 FAS9690P 1
Plain Washer M12 FAS2345P 2
Locknut M12 FAS2334 2
9 Housing Top Front Motor SC4686 1 Grease Nipple 1/4" BSF BRG5004 4
Setscrew M12 x 30 FAS2678P 8
Plain Washer M12 FAS2345P 16
Locknut M12 FAS2334 8
10 Upper Feed Passage Slide SC4689 1 Setscrew M12 x 30 FAS2678P 3
Setscrew M12 x 40 FAS2680P 1
Plain Washer M12 FAS2345P 8
Locknut M12 FAS2334 4
11 Lower Feed Passage Slide SC4584 1 Setscrew M12 x 30 FAS2678P 2
Plain Washer M12 FAS2345P 4
Locknut M12 FAS2334 2
12 Latch Arm SC4585 1 Setscrew M10 x 30 FAS2655P 1
Plain Washer M10 FAS2344P 2
Plain Washer M10 Form G FAS2344GP 1
Locknut M10 FAS2333 2
13 Upper Inspection Panel SC3909 1 Plain Washer M8 FAS2343P 5
Locknut M8 FAS2332 5
14 Pair Of 15mm Clamps HYD1960B 2 Clamp Top HYD1960C 2
Setscrew M8 x 35 FAS2631P 2
15 Side Inspection Panel SC4687 1 Plain Washer M8 FAS2343P 6
Locknut M8 FAS2332 6
16 Hydraulic Motor – 200cc HYD5232 1 Setscrew M12 x 35 FAS2679P 2
Plain Washer M12 FAS2345P 2
Locknut M12 FAS2334 2
Bonded Seal 1/2” BSP HYD4204 2
1/2” x
1/4” M/M Union HYD1114 2
Key 8 x 7 x 30mm FAS8134 1
Seal Kit - SAM Hydrauliks HYD4891 1
17 Spacer SC4209 1
18 Gear SC4208 1 Setscrew M8 x 25 FAS2629P 1
Plain Washer 30 x 9 x 5 FAS2408P 1
Spring Washer M8 FAS2353P 1
19 Spacer Segment - Small SC3707 2
20 Spacer Segment - Large SC3708 1
21 Drive Guard SC3710 1 Setscrew M10 x 20 FAS2652P 1
Plain Washer M10 FAS2344P 1
22 Clamp Segment SC3709 2 Setscrew M10 x 35 FAS2656P 10
Locknut M10 FAS2333 10
19
