Team C Hyde - Page 15

36
37
20
T02086 Small clip
……………5
T02084 M4 Flanged Nylon Nut
……………4
x2
Assemble as many times as specified
3°
3°
+3 deg
-3 deg
Body Mounting
Body Mounting
6mm
Drill holes with the specified diameter Cut off shaded portion
6mm
3mm
6mm
TG2032
T02086
TG2031
T02084
T02084
T02086
TG2032 M3x6 Screw
……………2
TG2032 M3 Nylon Nut
……………………2
TG2032
TG2032
TG2032
