Team C TC02C - Shock Absorber Assembly - Part 2; Shock Absorber Assembly - Step 25; Front Suspension Assembly - Step 26

Front-Short
Rear-Short
⸣
T02084 M3 Nylon Nut
………………2
………2
T02082 M3x15 Screw
T02082(M3x15)
T02084(M3)
Assemble as many times as specified Assemble both Left and RightAssemble both Left and Right
Shock Absorber
Front Suspension
11
T02094/T02095 12x1 O-ring
……………4
for adjusting the spring tension
Compress the spring and install
T02094/T02095
T02072(Long)
T02071(Short)
T02031
T02031
x2
x2
L
R
L
R
x2
L
R
L
R
25
26
x4
