Team C TC02C - Front Suspension Assembly - Part 3; Front Suspension Assembly - Steps 7, 8 & 9

Front Upper(Right)
Front Upper (Left)
Steering Tip
T02029 4.8mm Ball End(Long)
T02091 3x54 Turnbuckle
…………8
……4
4
Front Suspension
Front Suspension
……4
T02082 M3x10 Screw
……2
T02082 M3x22 Screw
T02063 5mm Ball stud
………………2
T02063
T02082(M3x10)
T02020
T02082(M3x22)
True-to -scale diagram Assemble as many times as specified
Front Suspension
T02091
T02029
T02029
approx.38mm
approx.38mm
approx.34mm
Projection.Note direction
Projection.Note direction
Projection.Note direction
T02093
T02093
T02092
T02092
T02093
T02093
T02093
7
9
1:1 x1
1:1 x1
1:1 x2
8
1:1 x2
