Team C TC02T Pro - Page 14

L
R
21
<Right>
22
<Left>
13
L
R
T02093 Ball stud - short
球頭-短
…………………2
T02034 2x9.8 Shaft
軸
T02100 5x10x4 Ball Bearing
軸承
……………4
T02057 3x30.5 Hinge pin Rear outer
後擺臂軸
…………………………4
…………2
T02057 2.3 E-ring
E扣
T02013 3.1x6x1 Plastic Washer
塑膠墊片
………………………2
Rear Suspension
後橋
L
R
左右裝法相同
Assemble left and right sides the same way
塗油脂
Apply grease
Rear Suspension
後橋
T02013
<右>
<左>
TG2012
T02100
T02100
T02034
T02034
…………………2
T02093
T02013
T02057
T02057
T02057
