KEYS AND PORTS
A. ITEM key: navigate between the various adjustable
parameters
B. VALUE key: modify the current parameter setting
C. RESET/PROFILE key: go to the memory prole selection
screen
D. SAVE key: save the modications to the ESC memory
E. USB port: used to connect the program box to a PC
computer
F. ESC connection port: used to connect the ESC to the
program box
G. Battery connector: used to connect the battery’s
balancing plug to check its charge status
CONNECTING THE ESC TO THE PROGRAM BOX
The dierent ESC types require dierent connection
methods to work with the program box.
• R10 Pro / R8.1 ESC w/dual sensor ports: use the special
sensor adapter (supplied with the ESC) and a regular
sensor wire connected to the top sensor port of the ESC.
• R8Pro ESCs: connect directly to the program box
• 1/10 – 1/8 100-130A RTR ESC: use the JR male-male cable
supplied with the program box and plug it into the cooling
fan connector located on the ESC.
