Inputs/outputs of the Alarm
Inputs/outputs of the Alarm are described in the following tables. Contact numbers are shown in Fig. 1. Configuration of inputs/outputs is programmed
(see Programming the Alarm hardware features).
1
2
9
18
1
10
4
8 5
2
4
1
3
Fig. 1. Numbers of port connector pins from wiring viewpoint
Table 4. Description of the systems main (18-pin) connector
Connector # Color Type Note Current, mA
18-pin
1 – Ground Power for additional devices (TP-BUS) –
2 Blue/Yellow – Heater WBUS(Webasto, Ebersacher) –
3 Brown CAN 2 CAN2-L bus –
4 Brown CAN 1 CAN1-L bus –
5 Pink/Green (+) programmable input Stop signal control 1,5
6 White/Black (-) output Wired engine lock 150
7 Gray/Black (-) programmable input Reference ground/Negative button 0,5
8 Yellow/Red Data link Connection between main unit and lock relay –
9 Black Ground Power –
10 – +12 V Power for additional devices (TP-BUS) –
11 – – TP-BUS (control bus for additional devices) –
12 Brown/Yellow CAN 2 CAN2-H bus –
13 Brown/Red CAN 1 CAN1-H bus –
14 Green/Black (-) programmable input Hood position control 1,5
15 Blue/Red (+/-) programmable output Turn signals alternate control ±150
16 Gray/Yellow (+) programmable input Analog buttons/Positive button 0,5
17 Pink/Black (+/-) output Siren control(+)/Horn control(-) 1,300/150
18 Red +12 V Power supply 1,500/10*
8-pin
1 Orange/Green (–) Programmable input Engine shutdown in remote start 1,5
2 Orange/White (+) Programmable input Disable alert if trunk is open 1,5
3 Yellow (+) mic rophone Microphone –
4 Black (–) microphone Microphone –
5 Yellow/White (–) Programmable output Front parking sensors control 150
6 Green/White (–) Programmable output Rear parking sensors control 150
7 Green (–) Programmable output
Impulse to close the hood/Alternate Central
Lock control (Lock for twin-wire control. Lock/
Unlock for one-wire central lock control)
150
8 Blue (–) Programmable output
Authentication pulse/Alternate Central Lock
control (Unlock for twin-wire Central Lock
control)
150
4-pin
1 Red/White Power supply +12 V power supply for Fortin or iDatalink
unit
2 Black/Yellow Power supply Ground for Fortin or iDatalink unit
3 Gray/Blue DATA(RX) connect to the
blue wire (Fortin) or black/
white (iDatalink) wire
Control of a Fortin or iDatalink unit
4 Gray/Green DATA(TX) connect to the
white wire (Fortin) or
black/white (iDatalink)
wire
Control of a Fortin or iDatalink unit
2-pin(LED)
1 Red (+) output +12 V power supply
2 Blue (–) output Ground
* Given is the average current value in operating and idle modes. It is subject to change according to positive outputs demand.
Useful current of output #9 depends on demand connected to negative outputs.
Outputs #6, 15, and 17 are protected from short-circuit, inductive eruptions, overheating, and overload.
Connector # Color Type Note Current, mA
18-pin
1 Black Ground
For TEC-810/830. Power for additional devices
For TEC-810/830 with thermal sensor
Ground for engine temperature sensor
–
2 Blue/Yellow – Heater WBUS (Webasto, Ebersacher) –
3 Brown CAN 2 CAN2-L bus –
4 Brown CAN 1 CAN1-L bus –
5 Pink/Green (+) programmable input Stop signal control 1,5
6 White/Black (-) output Wired engine lock 150
7 Gray/Black (-) programmable input Reference ground/Negative button 0,5
8 Yellow/Red Data link Connection between main unit and lock relay –
9 Black Ground Power –
10
For TEC-810/830.
Red
For TEC-810/830
with thermal
sensor Black/White
+12 V
For TEC-810/830. Power for additional devices
For TEC-810/830 with thermal sensor
Power for engine temperature sensor
–
11 – – TP-BUS (control bus for additional devices) –
12 Brown/Yellow CAN 2 CAN2-H bus –
13 Brown/Red CAN 1 CAN1-H bus –
14 Green/Black (-) programmable input Hood position control 1,5
15 Blue/Red
(+/-) programmable
output
Turn signals alternate control ±150
16 Gray/Yellow (+) programmable input Analog buttons/Positive button 0,5
17 Pink/Black (+/-) output Siren control(+)/Horn control(-) 1,300/150
18 Red +12 V Power supply 1,500/10*
8-pin
1 Orange/Green (–) Programmable input Engine shutdown in remote start 1,5
2 Orange/White (+) Programmable input Disable alert if trunk is open 1,5
3 Yellow (+) mi c rophone Microphone –
4 Black (–) microphone Microphone –
5 Yellow/White
(–) Programmable
output
Front parking sensors control 150
6 Green/White
(–) Programmable
output
Rear parking sensors control 150
7 Green
(–) Programmable
output
Impulse to close the hood/Alternate Central Lock
control (Lock for twin-wire control. Lock/Unlock
for one-wire central lock control)
150
8 Blue
(–) Programmable
output
Authentication pulse/Alternate Central Lock
control (Unlock for twin-wire Central Lock
control)
150
4-pin
1 Red/White Power supply +12 V power supply for Fortin or iDatalink unit
2 Black/Yellow Power supply Ground for Fortin or iDatalink unit
3 Gray/Blue DATA(RX) connect
to the blue wire
(Fortin) or black/white
(iDatalink) wire
Control of a Fortin or iDatalink unit
4 Gray/Green DATA(TX) connect
to the white wire
(Fortin) or black/white
(iDatalink) wire
Control of a Fortin or iDatalink unit
2-pin(LED)
1 Red (+) output +12 V power supply
2 Blue (–) output Ground
* Given is the average current value in operating and idle modes. It is subject to change according to positive outputs demand.
Useful current of output #9 depends on demand connected to negative outputs.
Outputs #6, 15, and 17 are protected from short-circuit, inductive eruptions, overheating, and overload.
