Overview
Back View
VIDEO L-in R-in
USB
COAX
HDMI
POWER
PC AUDIO IN
Y Pb Pr
USB:
USB jack for Recording and Media.
HDMI: Connect it to the HDMI of DVD or other equipment.
YPBPR: Connect them to the YPbPr video output terminal of DVD.
PC AUDIO IN: Connect it to the audio output terminal of PC.
VGA: For PC display. Connect it to the D-Sub 15 pins analog output connector of the PC.
COAX:Digital output to AV receiver.
HEADPHONE: Connect it to your headphone or other audio equipment.
RF: Connect antenna or cable 75 Ohm coaxial to receive TV signal.
POWER: Connect to the power.
Headphone
Video: Connect it to video output terminal of DVD.
L/R in: Connect them to audio output terminals of DVD, shared with YPbPr.
