8
symbol is displayed:
D – house heating, B – water heater priority,
R – parallel pumps, L – summer mode.
Pressing the encoder will move you to the main menu. The display shows two
options of the menu. To select a different option, turn the encoder knob.
.2. Changing the central heating and hot consumption
water setpoint temperature.
In order to change the setpoint temperature of the central heating (while in "C.H.
screen" main view), turn the encoder knob and (after setting a desired value) press it
to confirm the change.
In order to change the setpoint temperature of the hot consumption water (while
in "H.C.W. screen" main view), turn the encoder knob and (after setting a desired value)
press it to confirm the change.
Chapter "Screen" describes methods of changing the main screen view.
.3. Firing up
This function allows you to easily fire up the boiler. After igniting the boiler, you
need to activate an automatic fire-up cycle. By selecting optimum parameters, the
boiler uses the zPID function to smoothly switch to the duty mode. If the boiler reaches
the fire-up threshold temperature, the fan item will appear instead of the fire-up
function. From now on, the option will be used to activate/deactivate the fan. This
setting allows you to temporarily deactivate the fan at any time, e.g. while feeding fuel.
If during the fire-up cycle the boiler does not reach 40
O
C within 30 minutes, (default
parameters), the following warning message will appear on the display:
To restore the boiler to operation, switch off the alarm by pressing the
encoder and restarting the fire-up procedure.
.4. Manual Mode
For your convenience, the regulator features a manual mode module. In this mode,
each individual actuator is enabled and disabled independently of the other. In addition
to the Manual Mode function, the Blow Force function has been provided.
