Tech West ACL4D2 - Parts Breakdown

8
6
5
3
KEY PART NO. DESCRIPTION UNIT
1 CCH-115 115 V COPELAND COMPRESSOR HEAD 1HP 1
2 CCH-230 230 V COPELAND COMPRESSOR HEAD 1 HP 1
3 CF-115 115 V COOLING FAN 1
4 CF-230 230 V COOLING FAN 1
5 CFS-100 COMPRESSOR FAN SHROUD 1
6 CFG-100 FINGER GUARD 1
7 OSG-100 OIL SIGHT GLASS 1
HEAD COVER AND FAN ASSEMBLY
4
1
2
7
