FEATURES
This is a point-to-point extender kit, it can realize zero-latency transmission. The
4K@60Hz HDMI signal can be extended by 70m through CAT6/6A/7network cable.
It supports HDMI loop out, IR passthrough. 3.5 mm audio output, ...This is a reliable,
ultra-high-definition video transmission solution, which is widely used in security
monitoring, home theater, broadcasting, training and other fields.
• Zero-latency transmission
• Extend 4K@60Hz HDMI signal up to 70m over Cat6/6A/7 cable
• The receiver supports 3.5 mm stereo output
• Supports HDR10
• Supports EDID Passthrough and audio downscaling
• The transmitter supports HDMI loop out
• Supports IR passthrough
• Lightning protection, surge protection, EDS protection
PACKAGE CONTENTS
Make sure your package includes the following items:
• Transmitter unit *1
• Receiver unit *1
• Power supply DC5V/1A*2
• IR Blaster extension cable *1
• IR receiver extension cable *1
• Mounting brackets *4; screws *10
• User' s manual
INSTALLATION REQUIREMENTS
Signal source
Devices with HDMI port (PC, DVR, NVR, etc) HDMI cable ≤ 5m
Cable
Cat6/6A/7 following standard EIA-568B Cat6/6A/7 ≤ 70m
Display device
TV, projectors, … with HDMI port HDMI cable ≤ 5m
WALL MOUNTING
Install the mounting ears on the unit according with the diagram and select the wall
mounting position to fix it.
EN - 3
