PANEL DESCRIPTION
Transmitter (TX)
7
Reset button Press to restart the device
RJ45 signal
output
Connect with network cable
IR out Connect with IR blaster extension cable
Power/Signal
indicator
When there is power and no HDMI signal, the indicator will flash,
when there is HDMI signal, the indicator will light solid
DC5V power
input
Connect with DC5V/1A power adapter
HDMI output Connect with local HDMI display device with HDMI cable
HDMI input Connect with HDMI source device with HDMI cable
EN - 4
WWW.TECHLY.COM
HDMI EXTENDER
4K@60HZ
