mini HDmi EXTEnDER
EN
• Do notunplug the deive when it is in using, keep distance from
flammableandexplosivedevices.
• Powersupply:DC5V,usageonlythesuppliedpowerunit,donot
use the power supply if it is damaged.
FEATURES
ThisHDMI extenderoverCAT6extendstheHDMIcontent upto50
metersfor1080p.
Signal amplifier and zero signal loss.
TransmitHDsignal1080p60HzoversingleCAT6cableupto50m.
Sender(TX)ispoweredfromHDMIsourcesignalandReceiver(RX)
fromTVUSBport.
Plug and play with compact design.
PACKAGE CONTENTS
Makesureyourpackageincludesthefollowingitems:
•HDMItoRJ45senderTX*1
•R145toHDMIreceiver(RX)*1
•DC5V/1AMicroUSBpowerline*2
•Usermanual*1
INSTALLATION INFORMATION
• DonotmixupHDMIto R145 sender and RJ45 to HDMIreceiver
before installation.
•Donothotplugwhenitisworking.
•UseDC5Vpowersupplyonly.Makesurespecificationmatchedlf
using adapters not supplied by factory.
INSTALLATION REQUIREMENTS
• HDMI source device (computer graphics card, DVD, PS3, HD
monitoring equipment, etc).
• HDMIdisplaydevicelikeSDTV,HDTV,projectorwithHDMIport.
• UTP/STPCAT6/6A/7cablewithcoppercoreandexcellentquality
andfollowstandardEIA/TIA-568B.
