HDMI EXTENDER OVER CAT.5/5E/6
EN
•Donotunplugthedevicewhenitisinusing.
•Donot mix up HDMI to RJ45 senderandRJ45 to HDMI receiver
before installation.
•Powersupply:DC5V,usageonlythesuppliedpowerunit,donot
usethepowersupplyifitisdamaged.
INTRODUCTION
This HDMI Extender is a solution for transmission and extension
uncompressed full HD 1080p@60Hz HDMI signal over a signal
Cat5/5e/6 network cable. It includes a transmitter unit (TX) and a
receiverunit(RX),workingasapair.Longtransmissiondistanceisup
to120meterswithzerolatency.ThisHDMIExtendersupportIRpass
backfromremotecontrolsourcedevicefromreceiversiteeasily.This
productisperfectforAVtransmissioninapplicationofHDconference
system, HD video shooting, HD multimedia education system, HD
digital advertising and signage, etc.
FEATURES
1.Plugandplay,withoutinstallation
2.Includeatransmitterunit(TX)andareceiverunit(RX),workingas
a pair
3.Transmissiondistanceupto120mviaCat6cable,100mviaCat5e
cable,80mviaCat5cable
4.SupportIRpassbackforremotecontrolsourcedevicetoreceiver
siteeasily
5.Uncompressedandzerolatency
6.SupportresolutionisuptofullHD1080p@60Hz
7.CompliantwithCat5/5e/6forlongdistancetransmission
PACKAGE CONTENTS
•Transmitterunitx1pc
•Receiverunitx1pc
•PowersupplyDCSV/1Ax2pcs
•User‘smanualx1pc
•IRBlasterextensioncablex1pc
•IRreceiverextensioncablex1pc
INSTALLATION REQUIREMENTS
1.HDMI source device (computer graphics card, DVD,PS3, HD
monitoring equipment etc).
2.HDMI display device like SDTV, HDTV, and projector with HDMI
port.
3.UTP/STP Cat.5e/6 network cables, which following standard of
EIA-568B.
