HDMI EXTENDER OVER CAT.5/5E/6
EN
PANEL DESCRIPTION
1. Transmitter unit (TX)
➊
Resetbutton Restarttheunit
➋
RJ45signaloutput Connectwithnetworkcable
➌
LINKindicator LEDturnonallthetimewithHDMI 
 signaltransmission,flasheswithnosignal
transmission
➍
Powerinput ConnectwithDC5V1Apowersupply
➎
HDMIsignalinput ConnectwithHDMIsourcedevice
➏
IRsignaloutput ConnectwithIRblasterextensioncable
2. Receiver unit (RX)
➊
Resetbutton Restarttheunit
➋
R145signalinput Connectwithnetworkcable
➌
LINKindicator LEDturnsonallthetimewithHDMI 
 signaltransmission,flasheswithnosignal
transmission
➍
Powerinput ConnectwithDC5V1Apoweradapter
➎
HDMIsignaloutput Connectwiththedisplaydevice
➏
IRsignalinput ConnectwithIRreceiverextensioncable
➊ ➋ ➌ ➍ ➏➎
➊ ➋ ➌ ➍ ➏➎
