HDMI EXTENDER OVER CAT.5/5E/6
EN
IR USER GUIDE
1) IR blaster extensioncable should plugin the IROUT port ofTX
(Transmitter)unitofHDMIextenderandtheIRreceiverextension
cableshouldintheIRINportoftheRX(Receiver)unit.
2) TheemitteroftheIRblastershouldascloseaspossibletotheIR
receiverwindowofthesignalsourcedevice.
3) UsingtheIRremotecontrollerofthesignalsourcedevicetowards
the IR receiver (connected to the receiver), to remote control
sourcemediaplayback.
FAQ
Q: No image output?
A:1)Checkandmakesureallcablesareconnectedwell;
 2)RestarttheTX/RXby“RESET”button.
Q:RX“LINK”indicatorisflashingallthetime?
A:1) Make surenetwork cable connection follows the standard of
EIA-568B;
 2)Resetthetransmitterandreceiverandreconnect.
Q:Receiver“LINK”ledlightsonallthetimebutnoimageoutput?
A:1)MakesurethemonitorsupportsthecurrentHDMIsignalmode;
 2)MakesureHDMIcableiswellconnectedwithTV;
 3)Makesurethenetworkcableisfinecopperwires.
