CONNECTIONS
a. Point to point connection: up to 120 meters transmission
distance over single CAT6 (high quality cable can reach 150
meters)
H D M I I N
C ab l e
HDMI OUT
HDMI E X TENDER
TX( Sender )
HDMI E XTENDER
RX( R eceiver )
T V
HDMI E X TENDER
TX( Sender )
H D M I I N
D V D
Switch
C ab l e
HDMI OUT
T V HDMI E XTENDER
RX( R eceiver )
Switch*N
D V D
b. Router connection: by using network router/repeater, realize
unlimitedextension.
H D M I I N
C ab l e
HDMI OUT
HDMI E X TENDER
TX( Sender )
HDMI E XTENDER
RX( R eceiver )
T V
HDMI E X TENDER
TX( Sender )
H D M I I N
D V D
Switch
C ab l e
HDMI OUT
T V
HDMI E XTENDER
RX( R eceiver )
Switch*N
D V D
c. One-to-many connection:byusingnetworkrouter/switch,one
sendertoseveralreceivers,realizesextender&splitterfunction.
HDMI OUT
T V
HDMI E X TENDER
TX( Sender )
H D M I I N
D V D
HDMI E XTENDER
RX( R eceiver )
Switch
C ab l e
HDMI OUT
T V
HDMI E XTENDER
RX( R eceiver )
HDMI OUT
T V
HDMI E XTENDER
RX( R eceiver )
Note: Gigabit (1000Mbps) switcher is recommended in LAN
transmission.
IR USER GUIDE
1) IR blaster extension cable should plug-in the IR-out port of TX
(Sender) of HDMI extender and the IR receiver extension cable
should plug-in the IR-Out port of the RX (Receiver) of HDMI
extender.
2) The emitter of IR blaster should as close as possible to the IR
receiver of the signal source device.
3) UsingtheIRremotecontrollerofthesignalsourcedevicetowards
theIRreceiver(connectedtotheRXofHDMIextender),toremote
controlsourcemediaplayback.
