switcher and other POE power supply devices. The maximal
wattageofthetransmitterorreceiveris10wonly.
• The extender supports external 5V power supply for alternative.
Please do not connect POE switch and 5V power supply at the
sametime,chooseeachonewouldwork.
INTRODUCTION
HDMI HDBitT extender takes the advantages of the latest
transmission technology - HDbitT, extends your HDMI video/audio
with the resolutionof 1080p 60Hzup to120m (394feet) via single
network cable. Supports IR signal transmission, to control media
playbackofthesignalsourcedeviceatthedisplaylocation.Supports
POE.
FEATURES
• ExtendHDMIsignaloversingleCAT5e/6
• Transmissiondistanceupto394feet(120m)
• PoEfeatureprovidespowertothesenderand receiverunitsover
the link cable
• Supportresolutionsupto1080P@60Hz
• SupportIRpass-backfunction
• Compatiblewithexistingnetwork,notaffectinternet
• SupportconnectedwithPoEroutertosplitandextendHDMIsignal
unlimitedly
• HDMIandHDCPcompliant
PACKAGE CONTENTS
• HDMIEXTENDERsenderTXx1pc
• HDMIEXTENDERreceiverRXx1pc
• Usermanualx1pc
• IRBlasterextensioncablex1pc
• IRreceiverextensioncablex1pc
Note: above accessories are contented in the regular package for the
kit with transmitter and receiver. If buy HDMI Extender TX or HDMI
ExtenderRXseparately,thepackagecontentswouldbedifferent.
INSTALLATION REQUIREMENTS
1. HDMI source device (computer graphics card, DVD, PS3, HD
monitoringequipment,etc..)
2. HDMIdisplaydevicelikeSDTV,projectorwithHDMIport.
3. Network cables: UTP/STP Cat5e/6 networking cables, which
followingthestandardofEIA568B
Transmission length:CAT5E100m/CAT6120m
4. POE powered device: Support and compliant with IEEE802.3af
international standard switcher and other POE power supply
devices.Themaximalwattageofthetransmitterorreceiveris10w
only.
