Technaxx TX-153 User Manual

Technical specifications
Network
802.11b/g/n (WLAN) Encryption: WEP,
WPA, WPA2(PSK), WPS
Wi-Fi frequency
2.4Ghz
Max. radiated output
power
80mW
Wi-Fi distance
80m
Supported Files
WMA/MP3/AAC/AAC+/FLAC/WAV
Connections
DC, USB port, 3.5mm line out
Loud Speaker
2x 2W
Input
DC 5V/1.5A
Power consumption
7.5W
Material
ABS
Weight / dimension
590g / (L) 28.0 x (W) 11.0 x (H) 9.5cm
Package content
TX-153, power adapter, user manual
Troubleshooting
● If the device does not turn on after switching it on, or it turns off
after turning it on, check whether the correct voltage is supported to
the device. ● If the device doesn’t work correctly, unplug it from the
power source and/or make a factory reset. Note: all saved
favourites and settings will be lost. ● If the device can not connect
to the internet, check for the correct Wi-Fi settings. The device
needs to be in the near of the Wi-Fi repeater /router.
Warnings
● Only power the device with the included power adaptor. It would
make the device fail to work or even damage the headphone if it is
not powered with recommended voltage. ● Do not attempt to
disassemble the device, it may result in short-circuit or even damage.
● Do not drop or shake the device, it may break internal circuit boards
or mechanics. ● Keep the device in dry and ventilated environment.
Avoid high humidity and high temperature. ● This device is not water
resistant, therefore keep it away from moisture. ● Keep the device
away from little children.

Technaxx TX-153 Specifications

General

Radio type	Internet
Tuner type	Digital
Supported radio bands	-
RMS rated power	4 W
Number of built-in speakers	2
Display type	TFT
Display diagonal	2.4 \
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Headphone outputs	1
Headphone connectivity	3.5 mm
Projection	No
Product color	Black
Power source	DC
DC input voltage	5 V
Power consumption (typical)	7.5 W

Weight and Dimensions

Depth	280 mm
Width	110 mm
Height	95 mm
Weight	590 g
